Maximum height during operation
3500mm
Rated lifting capacity
2000kg
Power type
Battery
| Power type | Battery | Maximum lifting speed under no load/full load | 100mm/50mm/s |
| Rated lifting capacity | 2000kg | Maximum operating speed under no load/full load | 5.5/4.5km/h |
| Load center distance | 500mm | Maximum gradient (full load/no load) | 3/5% |
| Driving style | Standing driving type | Drive motor power | AC1.5kw |
| Overall length of the whole vehicle (pedaletracted) | 2030mm | Power of oil pump motor | 2.2kw |
| Overall vehicle width | 860mm | Overall mass under standard no-load conditio! | 710kg |
| Height of non lifting mast | 2080mm | Battery rated voltage | 12V120AH*2 |
| Maximum height during lifting | 3000mm | santry material | Manganese steel C-shaped steel |
| Maximum height during operation | 3500mm | Charger | 24V15A |
| Vinimum channel requirements | 2500mm | Dimension of carier wheel (front wheel) | 80*70mm |
| Vinimum ground clearance of fork | 85mm | Balance wheel size (rear wheel) | 125*50mm |
| Vinimum turning radius | 1612mm | Braking mode | Electromagnetic braking |
| Outside width of fork | 550/680mm | ork size(L*W*H) | 1100*160*50mm |
1 After-sales service is guaranteed, professional after-sales team
2 Comply with ISO and CE standards, strict production to ensure product quality.
